YUVIO TRACK
YUVIO TRACK is different: spotlights as modern design objects with a clear and recognizable shape. The luminaire head is square, flat and elegant with precise radii at the edges. And with a special technology for directing the light that stands out visibly: YUVIO works with freeform lenses, combining the advantages of reflector and lens technology in a striking aesthetic.
YUVIO TRACK in use
High-contrast, lively, focused: Paradigms that are standard in emotional retail lighting today. A new, perfect tool for this: a spotlight with a strong identity such as YUVIO TRACK. With the classic, rotationally symmetrical beam characteristics of Super Spot, Spot, Medium Flood and Flood plus a wide-area oval light distribution (34°x78), YUVIO TRACK illuminates typical retail areas just as attractively and efficiently as a wide variety of areas in other applications.
YUVIO TRACK spotlights can be rotated through 355° and swiveled from 0-110° - for a practical radius of action. They are available in the full range of our standard and special light colors. There is also the option to choose between switchable standard versions and LEDIQ for smart light management, via DALI or wireless with Bluetooth LE.
YUVIO freeform lenses
The freeform lenses are the visible feature of YUVIO's high-quality and unique lighting technology. They not only look different, but also offer superior properties: optimum precision of light distribution thanks to the specific lens contour with embossed reflector structure, excellent glare control, high efficiency with up to 160 lm/W.
white
medium
dark
Unique freeform lenses
Concise appearance, optimum precision and glare control
Universal application
In retail and beyond, for example for offices, hotels, restaurants or exhibitions
Horizontal and vertical
Accentuating, modeling or planar. The choice of light distributions guarantees creative freedom
Light colours also available in CRI > 90
Authentic illumination with Brilliant Colour, Brilliant Food, Efficient White or Efficient Cool, among others
Intelligent light
LEDIQ for your smart lighting management; controls from switchable, DALI, Bluetooth to BLE
Technical Specifications & Downloads
PLEASE SELECT LIGHTING
| Application areas | Gondola heads, high decorations, product carriers, back panels, graphics |
| LED Luminous Flux Class | 1500 lm - 5000 lm |
| Light colour | 2700 K, 3000 K, 3100 K - Brilliant Colour, 3200 K - Efficient White, 3500 K, 4000 K, 4000 K - Efficient Cool, 2700 K - Brilliant Food, Meat, Meat + Fish |
| Optic | Freeform lense |
| Supply unit | Driver |
| Material | Die-cast aluminium |
| Luminous Color | RAL 9005 jet black, RAL 9006 white aluminum, RAL 9016 traffic white |
| Weight | approx. 1.5 kg |
| Application areas | Gondola heads, high decorations, product carriers, back panels, graphics |
| LED Luminous Flux Class | 1500 lm - 5000 lm |
| Light colour | 2700 K, 3000 K, 3100 K - Brilliant Colour, 3200 K - Efficient White, 3500 K, 4000 K, 4000 K - Efficient Cool, 2700 K - Brilliant Food, Meat, Meat + Fish |
| Optic | Freeform lense |
| Supply unit | DALI Driver |
| Light Control | DALI DT6 |
| Installation | Recommended for new installation. |
| Mounting | Type: Global DALI |
| Material | Die-cast aluminium |
| Luminous Color | RAL 9005 jet black, RAL 9006 white aluminum, RAL 9016 traffic white |
| Weight | approx. 1.5 kg |
| Application areas | Gondola heads, high decorations, product carriers, back panels, graphics |
| LED Luminous Flux Class | 1500 lm - 5000 lm |
| Light colour | 2700 K, 3000 K, 3100 K - Brilliant Colour, 3200 K - Efficient White, 3500 K, 4000 K, 4000 K - Efficient Cool, 2700 K - Brilliant Food, Meat, Meat + Fish |
| Optic | Freeform lense |
| Supply unit | BLE Driver |
| Light Control | Bluetooth Low Energy |
| Installation | Recommended for modernization or new installation. In a BLE network up to 127 luminaires can be coupled. A stable Bluetooth connection depends on the particular local situation. In the case of this luminaire type it amounts to up to 25 m. |
| Material | Die-cast aluminium |
| Luminous Color | RAL 9005 jet black, RAL 9006 white aluminum, RAL 9016 traffic white |
| Weight | approx. 1.5 kg |
